CMC100 side entry magnetic mixer machine with High mixing efficiency for flotation

Large Image : CMC100 side entry magnetic mixer machine with High mixing efficiency for flotation Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	GEP
Certification:	ISO
Model Number:	CMC100
packing:	palstic inside, wooden case outside
certificate:	ISO9001:2008 SGS AAA
material quality:	SUS304, SUS316, SUS316L, etc.
weight:	266kg
impeller diameter:	100~350mm
power:	3KW
speed:	0~500rpm
type:	side entry
Additional Capabilities:	milling,coating,granulating,pigment,adhesive
Application:	liquid,solids,liquid with suspended solids,viscous fluid
Mixer Type:	Agitator

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	According to customer’s requirment
Delivery Time:	7-15days
Payment Terms:	Paypal,T/T, L/C

Contact Now

Detailed Product Description

High Light:

side entry mixers

side entry agitators

CMC100 side entry magnetic mixer machine with High mixing efficiency for flotation

1.side entry magnetic mixer machine
2.long service life: >10 years
3.delivery within 30 days
4.ISO9001:2008 SGS AAA

Feature:

1.No leaking in any time
2.Low power consumption
3.High mixing efficiency

Description:

1.This CMC100 side entry magnetic mixer machine adopts seal structure of segregation and static set and uses magnetic field lf strong magnetic to transmit torque without contact, so zero leakage can be ensured.

2.This series are commonly used in flammable, explosive, high pressure and toxic medium and other place.

Advantage:

the side-in mixer can reach the highest efficiency when consuming power and power consumption is only center mixer 1/3-2/3 .

Attention:

customers need to mark out using temperature and pressure, whether having the feature of solid particles and corrosion.

Main Technical Standards:

Series	Speed(rpm)	Power	A	B	D	D1	D2	f	n-do	DJ	Weight
CMC100	0-500	2.2	800	863	360	320	260	2	12-φ18	100-350	266
CMC100	0-500	3	800	863	360	320	260	2	12-φ18	100-350	266
CMC200	0-500	4	850	783	490	445	413	3	16-φ22	300-450	533
CMC200	0-500	5.5	850	783	490	445	413	3	16-φ22	300-450	533
CMC600	0-500	7.5	1050	819	595	555	518	3	20-φ26	400-550	795
CMC800	0-500	11	1380	1023	750	705	667	5	20-φ26	500-600	1050
CMC1200	0-500	15	1380	1023	860	810	772	5	24-φ26	500-700	1238
