GF1 portable diesel generator

portable diesel generator

1. 3-12KW series of ordinary diesel generating sets have been provided with high quality water-cooled (condenser) diesel engine, those engine can work well in every kinds conditions.
2. The structure of generating sets, the engine has been coupled with alternator though v-belt or coupled directly with alternator, both of them have been installed on the basis of anti-shock pad , the gen-sets has been fixed on the frame of steel pipes which has for wheels.
3. Other features
Easy to operate: it's easy to operate and maintain control panel capacitor type voltage regulator no-fuse circuit breaker over-current protection wheels type design double-shaft balance design electric starting. -

Other Main Performance
1. Voltage stead-state regulation ±10% fluctuation ratio 1.5% Transient-state regulation -15~20% stead time 5s.
Frequency stead-state regulation ±1% stead time 5s
2. The noise of gen-sets should be no more than 85db(a) The fuel consumption is no more than 2.5kg/kw.h.

-

-
