18KW - 20KW Portable Generator 1200 ℃ Fireproof Sound Insulation Sponge

Large Image : 18KW - 20KW Portable Generator 1200 ℃ Fireproof Sound Insulation Sponge Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	OUMA
Certification:	ISO,CE, SONCAP
Model Number:	OM18CY3

Payment & Shipping Terms:

Minimum Order Quantity:	5 units
Price:	To be negotiated
Packaging Details:	Plastic film and veneer case
Delivery Time:	50 working days
Payment Terms:	T/T or L/C at sight
Supply Ability:	50 units / day

Contact Now

Detailed Product Description

High Light:

RV diesel generators

silent diesel generator

18KW - 20KW Portable Generator 1200 ℃ Fireproof Sound Insulation Sponge

OUMA FAWDE series RV generators ranging from 8kw to 300kw are powered by China first top engine FAWDE.

Optional Choice: Kubota, Perkins, Cummins, Yanmar,etc. international well-known engine brands.

Description:

Our biggest features are low noise(57 - 62 dbA at 7 meters), samallest size and perfect cooling system(60℃ radiator, four-cavity design,central AC type cooling fan) which are always the aim for genset manufacturers to achieve.

Warranty:

Our warranty is 15 months or 1200 running hours, while most of factories is 12 months or 1000 hours.

Applications:

In China, OUMA is the leader in the LED broadcasting vehicle industry with more than 90% market share. Where is LED media vehicle, where is OUMA generator!

Specification:

Generator Set	Model	OM18CY3
	Brand	OUMA
	Rated power(KW)	18 20
	Rated voltage(V)	400/230 416/240
	Rated current(A)	32.4 34.6
	Rated frequency(Hz)	50 60
	Waveform distortion	Sinewave, distortion ≤5%
	Noise level(dB@7m)	62
	Battery(12V-Ah)	None
	Overall dimension (L×W×H)(mm)	≤ 1550x780x950
	Fuel tank capacity(L)	None
Diesel Engine	Model	OM498
	Brand	OUMA FAWDE
	Power output(KW)	25 30
	Type	Four cylinder, direct injection, four stroke
	Displacement(L)	2.6
	Bore×Stroke(mm)	98×95
	Rotation speed(r/m)	1500 1800
	Governor system	Mechanical
	Starting mode	12V DC
	Filter system	Dry air filter, fuel filter, oil filter
	Cooling type	Enclosed water-cooled
	Exhaust muffler	Downward
	Air inlet	Bottom
	Fuel consumption(g/kw.h)	≤220
	Oil capacity(L)	10
Alternator	Model	OM183C3
	Brand	OUMA
	Rated power(KW)	18 20
	Excitation mode	Brushless, self-excitation
	Voltage regulation	Auto regulation
	Number of phase	Three phase four wire
	Number of pole	4
	Rotation speed(R/M)	1500 1800
	Temperature rise(℃)	125
	Insulation grade(stator/rotor)	H/H
	Voltage regulation range w/o load	≥95%～105%
	Steady-state voltage deviation	Less ±1%
	Interference factor	TIF＜50,THF＜2%
	IP grade	IP22
Control Panel	Model	OM588
	Manufacturer	OUMA
	Power output	Terminal post
	Installation	In-built
	Manufacturer	OUMA
	Auto function	Manual/auto protection/shutdown, water temperature alarm, oil pressure alarm
	Parameter display	AC voltage, frequency, running hour, charging voltage

Competitive Advantage:

1. As the first biggest partner for FAWDE in genset application, OUMA receives best service and support from FAWDE.

2, Stamford or copy stamford brushless excitation and "H" class insulation alternator.

Original Stamford and copy Stamford alternator: No effect on noise level, still keep 57dbA at 7 meters. Parts are compatible.

3, Two big service doors with easy removal from the genset body,which can be installed in small space with easy accessibility for check and maintenance

4, 4-cavity design, Internal temperature of the genset housing is kept 40-50 ℃.

5, 60℃ radiator is used on all gensets so they can be used in all weather conditions

6. Central AC type cooling fan: 20,000 hours service life
